SRPP Topology

PERFORMANCE
INPUT SENSITIVITY FOR MAX SWING: 1.4V/rms (4V/pp)

INPUT IMPEDANCE: 10kOhm

VOLTAGE GAIN: +30dB

ATTENUATION: UP TO -96dB

(1dB STEP PASSIVE RELAY ATTENUATION)

POWER OUTPUT: 250W @ 8 Ohm

PEAK OUTPUT VOLTAGE: 125V/pp

FREQUENCY RANGE: 10Hz – 50kHz (-3dB)

OUTPUT NOISE: 1mV/pp

DYNAMIC RANGE: 120dB

THD+N AT 1 kHz: 0.1%

MAINS VOLTAGE: 230V/115V ~ (50/60Hz)

INPUTS: 4 x RCA

OPTIONAL AT REQUEST BUILT IN DAC: 2 x SPDIF | 1 x USB

SPEAKER TERMINAL: MUNDORF OFC PURE COPPER Ø8mm SILVER-PLATED

GENERAL
COLOR AND FINISH:

– BLACK ANODIZED ALU COVER WITH DIAMOND CUT EDGE
– SILVER ANODIZED ALU COVER WITH DIAMOND CUT EDGE

DIMENSIONS: WIDTH 489mm x HEIGHT 318mm x DEPTH 480mm

WEIGHT: 52kg
